Descrizione

FRAME Alu. Hydroformed 26″, easy access, integrated battery, internal cables
FORK Suntour NEX 26″, alu with alu crown, 50mm
HEADSET FSA integrated 1”1/8
CRANKSET AM80 alu 170mm, Miche 38T
REAR DERAILLEUR Shimano Tourney RD-TY500
SHIFTERS LEVERS Shimano Tourney SL-RS35 RevoShift, 7s
BRAKES Promax alu, V-Brake, levers 3 fingers
CASSETTE Shimano HG200 7s 12-32
PEDALS Resin antislip
HUB Shimano TX500 36h, quick release
RIMS Beretta 26″, double wall w/eylets, 36h
STEM Byte alu, ahead, adjustable
HANDLEBAR Byte steel City
SEATPOST Byte alu with clamp, 27,2mm
SADDLE Selle Royal Wave
TYRES Byte Garda 26”x1,75”, with reflecting line
MUDGUARDS Single stay speedy
CHAINCOVER Plastic, L type
CARRIERS Rear steel 10mm with spring, 25kg load
EXTERNAL LIGHTS Axa front (15 lux) and rear LED, controlled by display
MOTOR AM80 Agile CAN, 36V 250W
MAX TORQUE 80 Nm
SENSOR TYPE Torque
BATTERY Phylion Li-Ion 36V, 418Wh, on frame,
Samsung cells with Smart BMS CAN
CHARGER TYPE 2A Europlug
CHARGE TIME 100%: 6:30h / 80%: 4h40m
MAX ASSISTED SPEED 25 km/h
DISPLAY Atala A15 LED CAN, Power +/-
POWER 5 levels, Power adjust level1: 50%
level2: 100% level3: 150%
level4: 200% level5: 250%
OTHER FUNCTIONS Soft start: 0 – 6km/h, with no pedaling
External light control
WEIGHT Kg 26,8
